Simulation of a Perforated Vertical Wellbore with Near Wall Porous Media Effect

Haider S.  Mohammed; Hussein S.  Sultan; Emad A.  Khazal

doi:10.52716/jprs.v12i1.592

Authors

Haider S. Mohammed Department of Petroleum Engineering, College of engineering, University of Basra, Basra City, Iraq
Hussein S. Sultan Department of Petroleum Engineering, College of engineering, University of Basra, Basra City, Iraq
Emad A. Khazal Department of Petroleum Engineering, College of engineering, University of Basra, Basra City, Iraq

DOI:

https://doi.org/10.52716/jprs.v12i1.592

Keywords:

wellbore, perforation, permeability, porous media, Computational Fluid Dynamics.

Abstract

This paper aims to predict the effect of porous media permeability and perforations parameters on the pressure drop and productivity index, for the perforated vertical wellbore with six perforations and for two phase angles. The first 60ᵒ phase angle with helical distribution and the second 180ᵒ phase angle with normal distribution. In this study, a Computational Fluid Dynamics (CFD) software has been used to simulate a model of 3-D turbulent fluid flow with stander k−∈, steady-state, and single phase. The effect of the permeability of porous media, inlet mass flow rate from porous media, perforations length, and diameter of perforations are studied, for two cases of the phase angles. The results of this study show that, the pressure drop decreases with increasing permeability pf porous media, so the productivity index increasing. Also, increase of inlet mass flow rate from porous media causing an increase in the pressure drop. The perforations length has a few effects on the pressure drop and productivity index, while the diameter of perforations has a greater effect on the pressure drop.

References

Morris Muskat, "The Effect of Casing Perforations on Well Productivity," SPE. (1943); 151: 175-187.

Stanley Locke,"An Advanced Method for Predicting the Productivity Ratio of a Perforated Well," SPE. 1981; 23(12): 2481-2488.

M. Deo, S.M. Tariq, and P.M. Halleck,"Linear and Radial Flow Targets for Characterising Downhole Flow in Perforations," SPE. (1989); 4(3): 295-300.

Metin Karakas and S.M. Tariq,"Semianalytical Productivity Models for Perforated Completions," SPE. 1991; 5: 73-82.

Masaru Ihara, Koji Kikuyama and Keiichi Mizuguchi,"Flow in Horizontal Wellbores with Influx Through Porous Walls," SPE. 1994; 225-235.

Y.S. Dogulu,"Modeling of Well Productivity in Perforated Completions," SPE-51048-MS, pp. 109-118, (1998).

Yula Tang, Turhan Yildiz, Erdal Ozkan and Mohan G. Kelkar,"Effects of Formation Damage and High- Velocity Flow on the Productivity of Perforated Horizontal Wells,"SPE. 2005; 8: 315-324.

Joseph Ansah, Mark A. Proett and Mohamed Y. Soliman. Advances in Well Completion Design: A New 3D Finite-Element Wellbore Inflow Model for Optimizing Performance of Perforated Completions. SPE. 2002; 1-11.

E. Guerra and T. Yildiz," A Simple Approximate Method to Predict Inflow Performance of Selectively Perforated Vertical Wells," SPE.2004.

Turhan Yildiz. Assessment of Total Skin Factor in Perforated Wells. SPE. 2006; 9: 61-76.

Jacques Hagoort," An analytical model for predicting the productivity of perforated wells," Journal of Petroleum Science and Engineering. 2007; 56: 199–218.

Kuljabekov A.B., Inkarbekov M.K., Tungatarova M.S., Alibayeva K.A. and Kaltayev A ," Numerical Study of the Hydrodynamic Efficiency of the Multi-Stage Filter Setting Technology,"Archives of Mining Sciences. 2013; 58(3): 691-704.

Mahmoud O Elsharafi and Tibor Bodi,"Evaluation of the productivity of vertical oil wells by using different high shot density (HSD) guns, "International Journal of Petrochemical Science & Engineering. 2017.

Mohammed Abdulwahhab Abdulwahid, Sadoun Fahad Dakhil and I. N. Niranjan Kumar,"Numerical analysis of fluid flow properties in a partially perforated horizontal wellbore," American Journal of Energy Engineering. 2014; 2(6): 133-140.

Thomas Vyzikas," Application of numerical models and codes,"MERiFIC, 1st ed. (2014).

Awbi H. B. ," Ventilation of Buildings," M.Sc. thesis, London, NewYork, Taylor, Francis, (2005).

Harun Ates and M.G. Kelkar,"The Effect of Perforating on Oil Well Productivity," SPE. 1998; 2: 104-108.

Mohammed K Salim1, Hussein S Sultan1 and Ahmed KM AL-Shara,"Effect of Shape and Parameters of Perforation in a Vertical Wellbore with Two Perforations (without Porous Media) on Pressure Drop,"Fluid Mechanics. 2017.
